Digital Low Speed Diamond Saw with 4" Precision Blade & Complete accessories - EQ-SYJ-150
|
In stock
Item Number: EQ-SYJ-150
|
EQ-SYJ-150 low speed diamond saw equips with advanced digital micrometer and digital speed display controller, it is the perfect tool for cutting / dicing / slicing all kinds of materials up to 30 mm thickness, especially for brittle crystals, ceramics, TEM samples, and even plastic samples. MTI has made every effort to make the low speed diamond saw at such a high quality and low price. It makes the saw affordable by every research lab.
|
SPECIFICATION
|
|
Speed range
|
Variable 0-600 rpm with LED digital display
|
|
Power
|
AC 110V/220V switchable for worldwide usage
50W Max. Power consuming
|
|
Position accuracy
|
0.005mm
|
|
Max. travel distance
|
55mm in cross direction
|
|
Diamond Blades
|
SiC blade: 4" x 0.35 mm x 0.5" arbor for cutting nonferrous metal materials, such as super-alloys.
Al2O3 blade: 4" x 0.35 mm x 0.5" arbor for cutting ferrous metal materials, such as iron and steel.
Full sintered diamond blade: 4" x 0.35 mm x 0.5" arbor for cutting crystal, ceramic, and plastic materials
|
|
Water-proof LCD digital micrometer
|
Unit: millimeter (mm)
Minimum Readout Value :0.001 mm
Accuracy fits to manipulator arm: 0.003 mm
|
|
Package dimension
|
19" x 15" x 15"
|
|
Shipping weight
|
32 lbs
|
|
Warranty
|
two years limited (not including rusted parts due to inadequate storage conditions)
|
|
|
|
Standard Package
|
|
Part #
|
Standard items included on package
|
Qty.
|
Thumb Picture
|
|
EQ-SYJ-150
|
EQ-SYJ-150 Low Speed Diamond Saw
|
1 set
|
|
|
SYJ150-02
|
Adjustable Balance Weight with Shaft at Back Side ($80.00/ea)
|
1
|
|
|
SYJ150-03
|
Balance Weight at Front Side ($50.00/ea)
|
1
|
|
|
SYJ150-04
|
Goniometric Specimen Holder ($200.00/ea)
|
1
|
|
|
SYJ150-05
|
One Pair of Blade Clams, 35 mm dia. (1.4") ($40.00/pair)
|
1
|
|
|
SYJ150-06
|
One Pair of Blade Clams, 46 mm dia. (1.8") ($50.00/pair)
|
1
|
|
|
SYJ150-07
|
One Pair of Blade Clams, 62 mm dia. (2.45") ($70.00/pair)
|
1
|
|
|
SYJ150-08
|
Graphite Plate ($8.00/each)
|
2
|
|
|
SYJ150-09
|
Aluminum Plate ($5.00/ each)
|
2
|
|
|
SYJ150-10
|
Wax Rod for Mounting Sample ($10.00/ set)
|
1 set
|
|
|
SYJ150-11
|
One Fuse, Two M4 Screws
|
1 set
|
|
|
SYJ150-12
|
AC Power Cord
|
1
|
|
|
SYJ150-13
|
Screw Driver
|
1 set
|
|
|
SYJ150-14
|
O-ring of Driving Motor ($10.00/set)
|
1 set
|
|
|
SYJ150-15
|
A bag of 150-Lube Cutting Lubricant, 1 Oz/bag ($5.00/ bag)
|
1
|

|
|
SYJ150-16
|
Lubricant Tub
|
1
|

|
|
SYJ150-17
|
Collection Net
|
1
|

|
|
SYJ150-18
|
4" x 0.35mm x 0.5" Arbor Full Sintered Diamond Blade
|
1
|

|
|
SYJ150-19
|
4" x 0.35mm x 0.5" Arbor SiC Blade for Cutting Non-ferrous Metals
|
1
|

|
|
SYJ150-20
|
4" x 0.35mm x 0.5" Arbor Al2O3 Blade for Cutting Ferrous Metals
|
1
|

|
|
SYJ150-21
|
Dressing Stone for Sharpen and Reactivating Diamond blade
|
1
|

|
|
|
|
Optional Accessories
|
|
Part #
|
Optional items ( please click picture order separately)
|
Qty.
|
|
|
SYJ150-22
|
90 Degree Cross Vise ($129.00/ea)
|
Optional
|

|
|
SYJ150-23
|
Mini-vise (1 1/4" x 3/4" Jaw Width; 1" Max. Jaw Opening) ($120.00/ea)
|
Optional
|

|
|
SYJ150-24
|
Blade Spacer for Dicing Multiple Slices of Samples in parallel. 10 mm in Thickness; 60 mm in Diameter ($30.00/ea)
|
Optional
|

|

|
|
|
|
|
|
|
Sale Price: USD$14,995.00
|
|
|
| | |
|
| | |
|
