Digital Low Speed Diamond Saw with 6" Diamond Blade & complete accessories - SYJ-160
|
Click to enlarge
|
In stock
Item Number: SYJ-160
|
|
SYJ-160 is CE certified low speed diamond saw. The saw equips with advanced digital micrometer and digital speed display as well as complete accessories for 6" Max diamond blade. it is perfect tool for cutting / dicing / slicing all kinds of materials up to 55 mm thickness, especially for brittle crystals, ceramics, and TEM samples.
|
|
|
Part #
|
Standard items included on package
|
Qty.
|
Thumb Picture
|
| LSS001
|
SYJ-160 Low Speed Diamond Saw
|
1 set
|
|
| EQ-MHD-25C
|
Digital Micrometer Head 1" Travel 0.003 mm accuracy
|
1 set
|
|
|
|
LSS002
|
Adjustable Balance Weight with Shaft at Back Side ($80.00/ea)
|
1
|
|
|
LSS003
|
Balance Weight at Front Side ($50.00/ea)
|
1
|
|
|
LSS005
|
Goniometric Specimen Holder ($200.00/ea)
|
1
|
|
|
LSS021
|
One Pair of Blade Clams, 35 mm dia. (1.4") ($40.00/pair)
|
1
|
|
|
LSS006
|
One Pair of Blade Clams, 46 mm dia. (1.8") ($50.00/pair)
|
1
|
|
|
LSS007
|
One Pair of Blade Clams, 62 mm dia. (2.45") ($70.00/pair)
|
1
|
|
|
LSS008
|
Graphite Plate ($8.00/each)
|
2
|
|
|
LSS009
|
Aluminum Plate ($5.00/ each)
|
2
|
|
|
LSS010
|
2 pcs of high quality wax bulks for samples bounding
|
1 set
|
|
|
LSS012
|
One Fuse, Two M4 Screws
|
1 set
|
|
|
LSS013
|
AC Power Cord
|
1
|
|
|
LSS014
|
Screw Driver
|
1 set
|
|
|
LSS015
|
O-ring of Driving Motor ($10.00/set)
|
1 set
|
|
|
LSS016
|
A bag of 150-Lube Cutting Lubricant, 1 Oz/bag ($5.00/ bag)
|
1
|
|
|
LSS017
|
Lubricant Tub
|
1
|
|
|
LSS018
|
Collection Net
|
1
|
|
|
DB-153744
|
|
1
|
|
|
LSS019
|
6" x 0.5mm x 0.5" Arbor Abrasive SiC Blade for Cutting Non-ferrous Metals
|
1
|
|
|
LSS020
|
6" x 0.5mm x 0.5" Arbor Abrasive Al2O3 Blade for Cutting Ferrous Metals
|
1
|
|
|
LSS021
|
Dressing Stone for Sharpping and Reactivating Diamond blade
|
1
|
|
|
Part
|
Optional items ( please click picture order separately)
|
Qty
|
|
|
EC 401
|
90 Degree Cross Vise ($129.00/ea)
|
Optional
|
|
|
LSSO11
|
Mini Vise (1 1/4" x 3/4" Jaw Width; 1" Max. Jaw Opening) ($120.00/ea)
|
Optional
|
|
|
LSSO22
|
Blade Spacer for Dicing Multiple Slices of Samples in parallel. 10 mm in Thickness; 60 mm in Diameter ($30.00/ea)
|
Optional
|
|
|
LSS023
|
WD-40 3-IN-ONE Professional White Lithium Grease, 10.25oz
|
Optional
|
|
Warning:
|
|
|
|
|
|
|
|
Sale Price: USD$19,950.00
|
|
| | |
|
| | |
|
